电机类型：5RK
功率：120W
电压：110-380V
变速箱传动比：3-180K
|
型号 ·类型 上段：齿轮轴 下段()内：光轴 |
输出功率 W |
电压 V |
频率 Hz |
电流 A |
启动转矩 mN.m |
额定转矩 mN.m |
额定转速 r/min |
运行电容 μF |
|
|
引出线型 尺寸① |
接线盒型 尺寸② |
||||||||
|
5RK120GU-AF |
5RK120GU-AFT |
120 |
1ph 100 |
50 |
2.25 |
700 |
930 |
1250 |
35 |
|
60 |
2.85 |
750 |
1550 |
||||||
|
5RK120GU-EF |
5RK120GU-EFT |
120 |
1ph 110 |
60 |
1.90 |
650 |
750 |
1550 |
30 |
|
1ph 120 |
720 |
||||||||
|
5RK120GU-CF |
5RK120GU-CFT |
120 |
1ph 220 |
50 |
1.15 |
720 |
930 |
1250 |
8.0 |
|
1ph 230 |
|||||||||
|
5RK120GU-HF |
5RK120GU-HFT |
120 |
1ph 220 |
60 |
1.20 |
720 |
750 |
1550 |
8.0 |
|
1ph 230 |
|||||||||
|
类型 电动机/减速机 |
减速比 |
3 |
3.6 |
5 |
6 |
7.5 |
9 |
10 |
12.5 |
15 |
18 |
20 |
25 |
30 |
36 |
50 |
60 |
75 |
90 |
100 |
120 |
150 |
180 |
||
|
转速 r/min |
50Hz |
500 |
417 |
300 |
250 |
200 |
166 |
150 |
120 |
100 |
83 |
75 |
60 |
50 |
42 |
30 |
25 |
20 |
16 |
15 |
12 |
10 |
8 |
||
|
60Hz |
600 |
500 |
360 |
300 |
240 |
200 |
180 |
144 |
120 |
100 |
90 |
72 |
60 |
50 |
36 |
30 |
24 |
20 |
18 |
15 |
12 |
10 |
|||
| 5RK120GU-AF□ 5RK120GU-F口 5RK120GU-CF□ 5RK120GUHF□ |
5GU□RC |
容许转矩 |
50Hz |
1.50 |
1.80 |
2.51 |
3.01 |
4.73 |
5.01 |
5.57 |
7.89 |
9.47 |
10.0 |
11.1 |
15.8 |
18.9 |
20.0 |
20.0 |
20.0 |
20.0 |
20.0 |
20.0 |
20.0 |
20.0 |
20.0 |
|
14.7 |
17.7 |
24.6 |
29.5 |
48.3 |
49.1 |
54.6 |
80.5 |
96.6 |
98.3 |
109 |
161 |
193 |
200 |
200 |
200 |
200 |
200 |
200 |
200 |
200 |
200 |
||||
|
60Hz |
1.25 |
1.50 |
2.09 |
2.51 |
3.82 |
4.18 |
4.64 |
6.36 |
7.64 |
8.35 |
9.28 |
12.7 |
15.3 |
16.5 |
20.0 |
20.0 |
20.0 |
20.0 |
20.0 |
20.0 |
20.0 |
20.0 |
|||
|
12.3 |
14.7 |
20.5 |
24.6 |
39.0 |
40.9 |
45.5 |
64.9 |
77.9 |
81.9 |
91.0 |
130 |
156 |
168 |
200 |
200 |
200 |
200 |
200 |
200 |
200 |
200 |
||||
