电机类型：6IK
功率：120W
电压： 110-380V
变速箱传动比： 3-180K
|
型号 ·类型 引出线型 |
输出功率 W |
电压 V |
频率 Hz |
调速范围 r/min |
容许转矩 |
启动转矩 mN.m |
电流 A |
运行电容 μF |
|
|
齿轮轴型 |
1200r/min mN.m |
90r/min mN.m |
|||||||
|
6IK120RGU-AF |
120 |
1ph 100 |
50 |
90~1400 |
750 |
360 |
530 |
2.10 |
30 |
|
60 |
90~1700 |
2.50 |
|||||||
|
6IK120RGU-EF |
120 |
1ph 110 |
60 |
90~1700 |
750 |
360 |
520 |
1.70 |
20 |
|
1ph 120 |
1.80 |
||||||||
|
6IK120RGU-CF |
120 |
1ph 220 |
50 |
90~1400 |
750 |
330 |
530 |
0.95 |
8.0 |
|
1ph 230 |
|||||||||
|
6IK120RGU-HF |
120 |
1ph 220 |
60 |
90~1700 |
750 |
360 |
530 |
0.95 |
8.0 |
|
1ph 230 |
1.00 |
||||||||
|
类型 电动机/减速机 |
减速比 |
3 |
3.6 |
5 |
6 |
7.5 |
9 |
10 |
12.5 |
15 |
18 |
20 |
25 |
30 |
36 |
40 |
50 |
60 |
75 |
90 |
100 |
120 |
150 |
180 |
||
|
转速 r/min |
50Hz |
500 |
417 |
300 |
250 |
200 |
166 |
150 |
120 |
100 |
83 |
75 |
60 |
50 |
42 |
37 |
30 |
25 |
20 |
16 |
15 |
12 |
10 |
8 |
||
|
60Hz |
600 |
500 |
360 |
300 |
240 |
200 |
180 |
144 |
120 |
100 |
90 |
72 |
60 |
50 |
45 |
36 |
30 |
24 |
20 |
18 |
15 |
12 |
10 |
|||
|
6IK120RGU-AF□ 6IK120RGUF□ 6IK120RGU-CF□ 6IK120RGUHF□ |
6GU□RC 6GU□RT |
容许转矩 |
50Hz |
1.50 |
1.80 |
2.51 |
3.01 |
4.26 |
5.01 |
5.57 |
7.89 |
9.47 |
10.0 |
11.14 |
15.8 |
18.9 |
20.1 |
22.3 |
28.4 |
34.1 |
42.6 |
51.1 |
56.8 |
60.0 |
60.0 |
60.0 |
|
14.7 |
17.7 |
24.6 |
29.5 |
43.5 |
49.1 |
54.6 |
80.5 |
96.6 |
98.3 |
109 |
161 |
193 |
196 |
218 |
290 |
348 |
435 |
522 |
580 |
600 |
600 |
600 |
||||
|
60Hz- |
1.25 |
1.50 |
2.09 |
2.51 |
3.44 |
4.18 |
4.64 |
6.36 |
7.64 |
8.35 |
9.28 |
12.7 |
15.3 |
16.7 |
18.6 |
22.9 |
27.5 |
34.4 |
41.2 |
45.8 |
55.0 |
60.0 |
60.0 |
|||
|
12.3 |
14.7 |
20.5 |
24.6 |
35.1 |
40.9 |
45.5 |
64.9 |
77.9 |
81.9 |
91.0 |
130 |
156 |
164 |
182 |
234 |
280 |
351 |
421 |
467 |
561 |
600 |
600 |
||||
