型号 |
输出功率 |
电压 |
频率 |
额定电流 |
额定转矩 |
额定转速 |
堵转转矩 |
堵转电流 |
绝缘等级 |
|
W |
V |
Hz |
A |
N.m |
r/min |
N.m |
A |
||
|
ZDF3-45H□-2200-S |
2200 |
200 |
60 |
8.50 |
12.4 |
1700 |
34.00 |
52.00 |
F |
|
220 |
50 |
8.70 |
14.7 |
1430 |
70.00 |
69.00 |
|||
|
380 |
50 |
5.00 |
14.7 |
1430 |
70.00 |
40.00 |
|||
|
460 |
60 |
4.50 |
12.0 |
1740 |
83.00 |
46.00 |
|
型号 |
输出功率 |
电压 |
频率 |
额定电流 |
额定转矩 |
额定转速 |
堵转转矩 |
堵转电流 |
绝缘等级 |
|
W |
V |
Hz |
A |
N.m |
r/min |
N.m |
A |
||
|
ZDF3-40A□-2200-S |
2200 |
200 |
60 |
8.50 |
12.4 |
1700 |
34.00 |
52.00 |
F |
|
220 |
50 |
8.70 |
14.7 |
1430 |
70.00 |
69.00 |
|||
|
380 |
50 |
5.00 |
14.7 |
1430 |
70.00 |
40.00 |
|||
|
460 |
60 |
4.50 |
12.0 |
1740 |
83.00 |
46.00 |
|
功率 |
孔径/轴径 |
减速比 |
输出轴转速 |
输出轴容许转矩 |
输出轴容许 |
输出轴容许 |
|||
|
r/min |
N.m |
kgf.m |
轴向力负载 |
||||||
|
W |
mm |
i |
50Hz |
50Hz |
50Hz |
N |
kgf |
N |
kgf |
|
2200 |
45/40 |
5 |
300.0 |
58 |
5.920 |
3100 |
316 |
800 |
82 |
|
7.5 |
200.0 |
90 |
9.180 |
3500 |
357 |
900 |
92 |
||
|
10 |
150.0 |
120 |
12.24 |
3900 |
398 |
967 |
99 |
||
|
12 |
125.0 |
150 |
15.31 |
4100 |
418 |
1040 |
106 |
||
|
15 |
100.0 |
180 |
18.37 |
4400 |
449 |
1067 |
109 |
||
|
20 |
75.00 |
240 |
24.49 |
4700 |
480 |
1067 |
109 |
||
|
25 |
60.00 |
300 |
30.61 |
4700 |
480 |
1067 |
109 |
||
|
30 |
50.00 |
360 |
36.73 |
4700 |
480 |
1067 |
109 |
||
