型号 |
输出功率 |
电压 |
频率 |
额定电流 |
额定转矩 |
额定转速 |
堵转转矩 |
堵转电流 |
绝缘等级 |
|
W |
V |
Hz |
A |
N.m |
r/min |
N.m |
A |
||
|
ZDF3-45H□-1500-S(B) |
1500 |
200 |
60 |
7.10 |
8.70 |
1650 |
15.60 |
30.00 |
F |
|
220 |
50 |
6.70 |
10.2 |
1410 |
29.50 |
38.00 |
|||
|
ZDF3-45H□-1500-S₃ (B) |
380 |
50 |
3.70 |
10.2 |
1400 |
22.30 |
31.00 |
||
|
460 |
60 |
3.30 |
8.50 |
1740 |
31.60 |
24.00 |
|
型号 |
输出功率 |
电压 |
频率 |
额定电流 |
额定转矩 |
额定转速 |
堵转转矩 |
堵转电流 |
绝缘等级 |
|
W |
V |
Hz |
A |
N.m |
r/min |
N.m |
A |
||
|
ZDF3-40A□-1500-S(B) |
1500 |
200 |
60 |
7.10 |
8.70 |
1650 |
15.60 |
30.00 |
F |
|
220 |
50 |
6.70 |
10.2 |
1410 |
29.50 |
38.00 |
|||
|
ZDF3-40A□-1500-S₃ (B) |
380 |
50 |
3.70 |
10.2 |
1400 |
22.30 |
31.00 |
||
|
460 |
60 |
3.30 |
8.50 |
1740 |
31.60 |
24.00 |
|
功率 |
孔径/轴径 |
减速比 |
输出轴转速 |
输出轴容许转矩 |
输出轴容许 |
输出轴容许 |
|||
|
r/min |
N.m |
kgf.m |
轴向力负载 |
||||||
|
W |
mm |
i |
50Hz |
50Hz |
50Hz |
N |
kgf |
N |
kgf |
|
1500 |
45/40 |
5 |
300.0 |
41 |
4.230 |
2550 |
260 |
800 |
82 |
|
7.5 |
200.0 |
62 |
6.330 |
2940 |
300 |
900 |
92 |
||
|
10 |
150.0 |
83 |
8.460 |
3330 |
340 |
967 |
99 |
||
|
12 |
125.0 |
99 |
10.15 |
3630 |
370 |
1040 |
106 |
||
|
15 |
100.0 |
124 |
12.69 |
3920 |
400 |
1067 |
109 |
||
|
20 |
75.00 |
166 |
16.91 |
4070 |
415 |
1067 |
109 |
||
|
25 |
60.00 |
207 |
21.14 |
4460 |
455 |
1067 |
109 |
||
|
30 |
50.00 |
249 |
25.37 |
4700 |
480 |
1067 |
109 |
||
|
40 |
37.50 |
332 |
33.83 |
4750 |
485 |
1067 |
109 |
||
|
50 |
30.00 |
414 |
42.29 |
4750 |
485 |
1067 |
109 |
||
|
60 |
25.00 |
497 |
50.74 |
4750 |
485 |
1067 |
109 |
||
