型号 |
输出功率 |
电压 |
频率 |
额定电流 |
额定转矩 |
额定转速 |
堵转转矩 |
堵转电流 |
绝缘等级 |
|
W |
V |
Hz |
A |
N.m |
r/min |
N.m |
A |
||
|
ZDF3-35H□-750-S(B) ZDF3-45H□-750-S(B) |
750 |
200 |
60 |
3.45 |
4.22 |
1700 |
9.20 |
10.0 |
F |
|
220 |
50 |
4.24 |
5.00 |
1430 |
15.5 |
12.0 |
|||
|
380 |
50 |
2.45 |
5.00 |
1430 |
15.5 |
12.0 |
|||
|
460 |
60 |
2.28 |
4.12 |
1730 |
16.0 |
13.2 |
|
型号 |
输出功率 |
电压 |
频率 |
额定电流 |
额定转矩 |
额定转速 |
堵转转矩 |
堵转电流 |
绝缘等级 |
|
W |
V |
Hz |
A |
N.m |
r/min |
N.m |
A |
||
|
ZDF3-32A□-750-S(B) ZDF3-40A□-750-S(B) |
750 |
200 |
60 |
3.45 |
4.22 |
1700 |
9.20 |
10.0 |
F |
|
220 |
50 |
4.24 |
5.00 |
1430 |
15.5 |
12.0 |
|||
|
380 |
50 |
2.45 |
5.00 |
1430 |
15.5 |
12.0 |
|||
|
460 |
60 |
2.28 |
4.12 |
1730 |
16.0 |
13.2 |
|
功率 |
孔径/轴径 |
减速比 |
输出轴转速 |
输出轴容许转矩 |
输出轴容许 |
输出轴容许 |
|||
|
r/min |
N.m |
kgf.m |
轴向力负载 |
||||||
|
W |
mm |
i |
50Hz |
50Hz |
50Hz |
N |
kgf |
N |
kgf |
|
750 |
35/32 |
5 |
300.0 |
21 |
2.110 |
1960 |
200 |
500 |
51 |
|
7.5 |
200.0 |
30 |
3.100 |
2250 |
230 |
567 |
58 |
||
|
10 |
150.0 |
41 |
4.230 |
2450 |
250 |
613 |
63 |
||
|
12 |
125.0 |
50 |
5.070 |
2600 |
265 |
669 |
68 |
||
|
15 |
100.0 |
62 |
6.340 |
2740 |
280 |
686 |
70 |
||
|
20 |
75.00 |
83 |
8.460 |
2990 |
305 |
747 |
76 |
||
|
25 |
60.00 |
104 |
10.57 |
3190 |
326 |
796 |
81 |
||
|
30 |
50.00 |
124 |
12.69 |
3280 |
335 |
821 |
84 |
||
|
40 |
37.50 |
166 |
16.91 |
3480 |
355 |
870 |
89 |
||
|
50 |
30.00 |
207 |
21.14 |
3480 |
355 |
870 |
89 |
||
|
60 |
25.00 |
249 |
25.37 |
3480 |
355 |
870 |
89 |
||
|
45/40 |
80 |
18.80 |
298 |
30.45 |
4750 |
485 |
1177 |
120 |
|
|
100 |
15.00 |
373 |
38.06 |
4750 |
485 |
1177 |
120 |
||
|
120 |
12.50 |
448 |
45.67 |
4750 |
485 |
1177 |
120 |
||
|
※160 |
9.400 |
554 |
56.53 |
5190 |
530 |
1275 |
130 |
||
|
※200 |
7.500 |
554 |
56.53 |
5190 |
530 |
1275 |
130 |
||
|
※240 |
6.300 |
554 |
56.53 |
5190 |
530 |
1275 |
130 |
||
