型号 |
输出功率 |
电压 |
频率 |
额定电流 |
额定转矩 |
额定转速 |
堵转转矩 |
堵转电流 |
绝缘等级 |
|
W |
V |
Hz |
A |
N.m |
r/min |
N.m |
A |
||
|
ZDF3-30H□-400-S(B) ZDF3-35H□-400-S(B) |
400 |
200 |
60 |
1.97 |
2.31 |
1650 |
3.80 |
7.5 |
F |
|
220 |
50 |
2.00 |
2.75 |
1380 |
6.90 |
9.5 |
|||
|
380 |
50 |
1.19 |
2.75 |
1380 |
6.90 |
5.5 |
|||
|
460 |
60 |
1.11 |
2.20 |
1730 |
7.30 |
6.3 |
|
型号 |
输出功率 |
电压 |
频率 |
额定电流 |
额定转矩 |
额定转速 |
堵转转矩 |
堵转电流 |
绝缘等级 |
|
W |
V |
Hz |
A |
N.m |
r/min |
N.m |
A |
||
|
ZDF3-28A□-400-S(B) ZDF3-32A□-400-S(B) |
400 |
200 |
60 |
1.97 |
2.31 |
1650 |
3.80 |
7.5 |
F |
|
220 |
50 |
2.00 |
2.75 |
1380 |
6.90 |
9.5 |
|||
|
380 |
50 |
1.19 |
2.75 |
1380 |
6.90 |
5.5 |
|||
|
460 |
60 |
1.11 |
2.20 |
1730 |
7.30 |
6.3 |
|
功率 |
孔径/轴径 |
减速比 |
输出轴转速 |
输出轴容许转矩 |
输出轴容许 |
输出轴容许 |
|||
|
r/min |
N.m |
kgf.m |
轴向力负载 |
||||||
|
W |
mm |
i |
50Hz |
50Hz |
50Hz |
N |
kgf |
N |
kgf |
|
400 |
30/28 |
5 |
300.0 |
11 |
1.130 |
1520 |
155 |
375 |
38 |
|
7.5 |
200.0 |
17 |
1.730 |
1760 |
180 |
438 |
45 |
||
|
10 |
150.0 |
22 |
2.260 |
1910 |
195 |
475 |
48 |
||
|
12 |
125.0 |
27 |
2.710 |
2060 |
210 |
506 |
52 |
||
|
15 |
100.0 |
33 |
3.380 |
2160 |
220 |
539 |
55 |
||
|
20 |
75.00 |
44 |
4.510 |
2400 |
245 |
600 |
61 |
||
|
25 |
60.00 |
55 |
5.640 |
2550 |
260 |
637 |
65 |
||
|
30 |
50.00 |
66 |
6.770 |
2650 |
270 |
662 |
68 |
||
|
40 |
37.50 |
88 |
9.020 |
2840 |
290 |
711 |
73 |
||
|
50 |
30.00 |
111 |
11.28 |
2990 |
305 |
747 |
76 |
||
|
60 |
25.00 |
133 |
13.53 |
3090 |
315 |
767 |
78 |
||
|
35/32 |
80 |
18.80 |
159 |
16.24 |
3480 |
355 |
873 |
89 |
|
|
100 |
15.00 |
199 |
20.30 |
3530 |
360 |
833 |
85 |
||
|
120 |
12.50 |
239 |
24.36 |
3530 |
360 |
833 |
85 |
||
|
※160 |
9.400 |
270 |
27.55 |
3630 |
370 |
912 |
93 |
||
|
※200 |
7.500 |
270 |
27.55 |
3630 |
370 |
912 |
93 |
||
|
※240 |
6.300 |
270 |
27.55 |
3630 |
370 |
912 |
93 |
||
