型号 |
输出功率 |
电压 |
频率 |
额定电流 |
额定转矩 |
额定转速 |
堵转转矩 |
堵转电流 |
绝缘等级 |
|
W |
V |
Hz |
A |
N.m |
r/min |
N.m |
A |
||
|
ZDF3-25H□-200-S(B) ZDF3-30H□-200-S(B) |
200 |
200 |
60 |
1.10 |
1.12 |
1700 |
2.25 |
4.93 |
F |
|
220 |
50 |
1.35 |
1.36 |
1400 |
3.50 |
5.40 |
|||
|
380 |
50 |
0.78 |
1.36 |
1400 |
3.50 |
3.10 |
|||
|
460 |
60 |
0.78 |
1.12 |
1740 |
3.80 |
3.75 |
|
型号 |
输出功率 |
电压 |
频率 |
额定电流 |
额定转矩 |
额定转速 |
堵转转矩 |
堵转电流 |
绝缘等级 |
|
W |
V |
Hz |
A |
N.m |
r/min |
N.m |
A |
||
|
ZDF3-22A□-200-S(B) |
200 |
200 |
60 |
1.10 |
1.12 |
1700 |
2.25 |
4.93 |
F |
|
220 |
50 |
1.35 |
1.36 |
1400 |
3.50 |
5.40 |
|||
|
380 |
50 |
0.78 |
1.36 |
1400 |
3.50 |
3.10 |
|||
|
460 |
60 |
0.78 |
1.12 |
1740 |
3.80 |
3.75 |
|
功率 |
孔径/轴径 |
减速比 |
输出轴转速 |
输出轴容许转矩 |
输出轴容许 |
输出轴容许 |
|||
|
r/min |
N.m |
kgf.m |
轴向力负载 |
||||||
|
W |
mm |
i |
50Hz |
50Hz |
50Hz |
N |
kgf |
N |
kgf |
|
200 |
25/22 |
5 |
300.0 |
5.5 |
0.560 |
1230 |
126 |
307 |
31 |
|
7.5 |
200.0 |
8 |
0.790 |
1370 |
140 |
342 |
35 |
||
|
10 |
150.0 |
11 |
1.130 |
1520 |
155 |
380 |
39 |
||
|
12 |
125.0 |
13 |
1.350 |
1620 |
165 |
405 |
41 |
||
|
15 |
100.0 |
17 |
1.690 |
1720 |
176 |
429 |
44 |
||
|
20 |
75.00 |
22 |
2.260 |
1860 |
190 |
466 |
48 |
||
|
25 |
60.00 |
28 |
2.820 |
2010 |
205 |
502 |
51 |
||
|
30 |
50.00 |
33 |
3.380 |
2110 |
215 |
527 |
54 |
||
|
40 |
37.50 |
44 |
4.510 |
2300 |
235 |
576 |
59 |
||
|
50 |
30.00 |
55 |
5.640 |
2450 |
250 |
613 |
63 |
||
|
60 |
25.00 |
66 |
6.770 |
2550 |
260 |
637 |
65 |
||
|
30/28 |
80 |
18.80 |
80 |
8.120 |
3090 |
315 |
775 |
79 |
|
|
100 |
15.00 |
99 |
10.15 |
3140 |
320 |
785 |
80 |
||
|
120 |
12.50 |
119 |
12.18 |
3140 |
320 |
785 |
80 |
||
|
160 |
9.400 |
159 |
16.24 |
3140 |
320 |
785 |
80 |
||
|
※200 |
7.500 |
184 |
18.80 |
3140 |
320 |
785 |
80 |
||
|
※240 |
6.300 |
184 |
18.80 |
3140 |
320 |
785 |
80 |
||
