产品类型：直齿系列行星减速器
产品尺寸：40-160
减速比：一级：3-10
二级：9-64
三级：60-512
回程间隙：一级：6-12弧分
二级：15-22弧分
|
产品型号 |
40 |
60 |
80 |
120 |
160 |
减速比 |
级数 |
|
|
额定输出转矩 |
N.M |
4.5 |
12 |
40 |
80 |
400 |
3 |
1 |
|
6 |
16 |
50 |
110 |
450 |
4 |
|||
|
6 |
16 |
50 |
110 |
450 |
5 |
|||
|
5 |
15 |
45 |
100 |
400 |
8 |
|||
|
4 |
12 |
40 |
80 |
305 |
10 |
|||
|
/ |
40 |
100 |
210 |
/ |
9 |
2 |
||
|
16.5 |
40 |
100 |
210 |
700 |
12 |
|||
|
16.5 |
40 |
100 |
210 |
700 |
15 |
|||
|
20 |
44 |
120 |
260 |
800 |
16 |
|||
|
20 |
44 |
120 |
260 |
800 |
20 |
|||
|
18 |
40 |
110 |
230 |
700 |
25 |
|||
|
20 |
44 |
120 |
260 |
800 |
32 |
|||
|
18 |
40 |
110 |
230 |
700 |
40 |
|||
|
7.5 |
18 |
45 |
100 |
400 |
64 |
|||
|
16.5 |
40 |
100 |
210 |
/ |
60 |
3 |
||
|
20 |
44 |
120 |
260 |
/ |
80 |
|||
|
20 |
44 |
120 |
260 |
/ |
100 |
|||
|
16.5 |
40 |
100 |
210 |
/ |
120 |
|||
|
20 |
44 |
120 |
260 |
/ |
160 |
|||
|
18 |
40 |
110 |
230 |
/ |
200 |
|||
|
20 |
44 |
120 |
260 |
/ |
256 |
|||
|
18 |
40 |
110 |
230 |
/ |
320 |
|||
|
7.5 |
18 |
45 |
100 |
/ |
512 |
|||
|
寿命 |
小时 |
20,000 |
||||||
|
瞬间急停扭矩 |
N.M |
2倍于额定输出扭矩 |
||||||
|
产品型号 |
40 |
60 |
80 |
120 |
160 |
单位 |
级数 |
|
最大径向力 |
160 |
450 |
900 |
2100 |
6000 |
N |
|
|
最大轴向力 |
80 |
225 |
450 |
1050 |
3000 |
N |
|
|
满载效率 |
96 |
% |
1 |
||||
|
94 |
2 |
||||||
|
90 |
3 |
||||||
|
重量 |
0.4 |
0.9 |
2.1 |
6 |
18 |
Kg |
1 |
|
0.5 |
1.1 |
2.6 |
8 |
22 |
2 |
||
|
0.6 |
1.3 |
3.1 |
9.5 |
/ |
3 |
||
|
使用温度 |
-25~+90 |
℃ |
|||||
|
防护等级 |
IP54 |
||||||
|
润滑方式 |
终身润滑 |
||||||
|
安装方式 |
任意 |
||||||
|
产品型号 |
40 |
60 |
80 |
120 |
160 |
减速比 |
|
|
转动惯量 |
Kgcm² |
0.031 |
0.135 |
0.77 |
2.63 |
12.14 |
3 |
|
0.022 |
0.093 |
0.52 |
1.79 |
7.78 |
4 |
||
|
0.019 |
0.078 |
0.45 |
1.53 |
6.07 |
5 |
||
|
0.017 |
0.065 |
0.39 |
1.32 |
4.63 |
8 |
||
|
0.015 |
0.054 |
0.34 |
1.14 |
3.52 |
10 |
||
|
/ |
0.131 |
0.74 |
2.62 |
/ |
9 |
||
|
0.022 |
0.088 |
0.50 |
2.56 |
7.47 |
12 |
||
|
0.019 |
0.077 |
0.44 |
1.79 |
6.65 |
15 |
||
|
0.022 |
0.088 |
0.50 |
1.75 |
7.47 |
16 |
||
|
0.019 |
0.075 |
0.44 |
1.50 |
6.65 |
20 |
||
|
0.019 |
0.075 |
0.44 |
1.49 |
5.81 |
25 |
||
|
0.017 |
0.064 |
0.39 |
1.30 |
4.50 |
32 |
||
|
0.016 |
0.064 |
0.39 |
1.30 |
4.50 |
40 |
||
|
0.016 |
0.064 |
0.39 |
1.30 |
4.50 |
64 |
||
|
0.019 |
0.075 |
0.50 |
1.50 |
/ |
60 |
||
|
0.019 |
0.075 |
0.50 |
1.50 |
/ |
80 |
||
|
0.019 |
0.075 |
0.44 |
1.49 |
/ |
100 |
||
|
0.016 |
0.064 |
0.39 |
1.30 |
/ |
120 |
||
|
0.016 |
0.064 |
0.39 |
1.30 |
/ |
160 |
||
|
0.016 |
0.064 |
0.39 |
1.30 |
/ |
200 |
||
|
0.016 |
0.064 |
0.39 |
1.30 |
/ |
256 |
||
|
0.016 |
0.064 |
0.39 |
1.30 |
/ |
320 |
||
|
0.016 |
0.064 |
0.39 |
1.30 |
/ |
512 |
|
产品型号 |
40 |
60 |
80 |
120 |
160 |
级数 |
|
|
回程间隙 |
弧分 |
<12 |
<8 |
<8 |
<8 |
<8 |
1 |
|
<15 |
<12 |
<12 |
<12 |
<12 |
2 |
||
|
<18 |
<15 |
<15 |
<15 |
/ |
3 |
|
产品型号 |
40 |
60 |
80 |
120 |
160 |
|
|
抗扭钢性 |
N.M/arcmin |
0.7 |
1.8 |
4.5 |
12 |
38 |
|
噪声 |
dB(A) |
55 |
58 |
60 |
65 |
70 |
|
最高输入转速 |
min-¹ |
4500 |
4500 |
4500 |
4500 |
4500 |
|
推荐输入转速 |
min-¹ |
3000 |
3000 |
3000 |
3000 |
3000 |
